High temperature Tube Furnace HT 1500

Orbit MEA Logo
Overview

Tube furnaces are one of the most effective ways to heat a small sample while allowing rapid temperature changes and temperature uniformity. The HT 1500 can be used for preheating of ceramic crucibles for induction furnaces.

Each time a crucible is needed, a new one is inserted into the tube, and a preheated crucible falls out the other end of the furnace tube. The recommended preheating temperature is between 1250°C and 1350°C.

Features
  • The temperature of this furnace is adjustable up to 1500°C.
  • The combustion tube has an inner diameter of 60 mm and a hot zone of about 200 mm.
  • The temperature, which is digitally displayed, can be adjusted with an accuracy right down to 1° C.
  • The platform on the front-side of the furnace serves to carry samples for the analyses, as well as their hot remainders, once extracted from the furnace.
Models
  • High temperature Tube Furnace HT 1500​
  • High temperature Tube Furnace HT 1800
